Products Description

The livestock farm cooling fan in our DCHVLS PMSM range is built around animal comfort rather than worker comfort alone. A gearless permanent-magnet synchronous motor turns a large airfoil rotor slowly, pushing a broad, gentle column of air across animals at standing height. Unlike small high-speed fans that create stressful drafts and kick up dust, the HVLS rotor moves large volumes of air at low peripheral speed, which strips away the still, hot boundary layer around animals and reduces heat stress without startling the herd or flock. The same slow airflow breaks up hot and cold stratification inside barns, so stock in the middle and at the ends of the building share the same temperature instead of suffering under a hot roof. Because the drive is gearless and runs on heavy-duty silent bearings, the fan operates quietly enough not to agitate nervous animals during long summer shifts.

Farm buyers often need a fan adapted to unusual barn roof structures, which is why structural customization is central to this product. We adjust blade diameter, blade count and mounting brackets to the existing truss or beam layout, and we manufacture to your technical drawings or prototypes rather than forcing a fixed ceiling height. The same gearless PMSM platform can be specified as a single large unit over the central pen or split into several parallel units down the barn, with the power supply set to whatever voltage your farm distribution already carries.

Specifications

Parameter	Specification
Motor type	Gearless PMSM direct drive, silent heavy-duty bearings
Blade diameter	2000–7300 mm
Blade count	5–8
Motor power	0.4–1.8 kW
Power supply	380 V 3-phase / 220 V single-phase, 50/60 Hz
Max speed	55–120 RPM
Air volume	2,560–15,000 m³/min
Coverage	50–920 m²
Air movement	Slow, broad, omni-directional, low peripheral speed
Mounting	Clamped to roof beams, ≥ 4.5 m floor height

Applications

Dairy barns

slow, wide airflow removes the hot boundary layer around cows lying down, reducing heat stress that suppresses milk yield during summer.

Poultry houses

low peripheral speed and silent operation move air through the flock without creating the startle response caused by high-velocity small fans.

Horse stables and holding barns

gentle, even circulation prevents stale, ammonia-heavy air from sitting at animal height while keeping dust disturbance to a minimum.

Customization

Structural customization of brackets and rotor size to your barn roof beams, manufactured to your technical drawings or prototypes.
Blade diameter 2000–7300 mm and blade count 5–8, matched to pen layout and building length.
Motor power 0.4–1.8 kW, supplied for 380 V 3-phase or 220 V single-phase to match farm electrical supply.
Clamped mounting to roof structure beams, suitable for multi-unit parallel circulation along a barn.

Packaging & Transportation

Every fan is fully tested and 100% inspected before packing in fumigation-free plywood wooden cases. We ship on EXW, FOB, DDP or CIF terms, with photo and video progress updates during production.

FAQ

Q1. How long is the warranty?

A: Each unit carries a 3-year whole-unit warranty. Free replacement parts are provided during the warranty period except in cases of misuse, and parts are free if shipping damage affects use.

Q2. How is the fan packed for shipment to a farm site?

A: Standard export packing uses fumigation-free plywood wooden cases, which are accepted for direct shipment without additional fumigation.

Q3. What is the minimum order quantity?

A: MOQ is 1 unit. Mixed colors and models are allowed, so you can start with one fan over the central pen and add units as needed.
